Airfield Signage

Sustainable Technology

High Quality LED based. 75% percent Energy reduction. 7 Years Maintenance cycle. 60% less cost of ownership

Product Range

Height Range (mm) 600 l 800 l 900 l 1200 (Mandatory Signs)
Width Range (mm) on clients Specifications
Depth (mm) 220mm

Energy Consumption

LED lightsource 20 Watt / Meter

Light and Electrical

Super Led sources with 100 000 hours life expectancy , approximately replaceing once every 10 years, high performance converter for 6.6 Amp Constant Current Circuits, 24 V, Eartch safety connections included

Mechanical

Aluminium Base materials, white interior finish, tellow exterior finish, Aluminium Galvinised Tubing for framework, weather resistant IP65, Breakaway couplings and Wind Load according to latest ICAO standards. CEAG EXANTICOND M25nAirlock for Anti-condensation.
.

Compliance

FAA Advisory Circular 150/5345-44F. All sysytems adhere to required specifications.

Maintenance

LED lightsource replacement once every 10 years

Options

Bird Deterrent, Spikes will prevent birds from resting on top of the TG units.
Safety ropes prevent signs being blown in case of exceeding or accidental blow down during excessive winf force or jet blast IP54 switch to cut off unit from 6.6 Amp Circuit.

" Over 35 years experience in the delivery of way finding signage for small and large projects"
